15" Panel PC, support P-4, Celeron, Dual core, Core 2 Duo socket 775 series CPUs, Touch screen, support up to 4GB DDR-2 high speed RAM, SATA-II high speed HDD, LAN, VGA, 64MB Shared RAM, 8 x USB 2.0 , 1 Serial port, 2 x Speakers , CD-ROM


Support all kinds of Intel socket 775 series CPUs :
- Core 2 Duo 64-bit CPU
- P-4 2.8G Dual Core CPU
- Celeron 2.6G, 2.8G, etc.

System Chipset

The high level VIA P4M890 northbridge
VT8623 and VT 823 7A southbridge

Front Bezel & Housing

10mm solid aluminum brushed anodized high-end bezel.
Whole housing is made of 1.2mm thick rugged steel construction housing


Housing is made of 1.2mm thick rugged steel anti-corrosive plate construction

LCD Technical Data Size : 1 5-inch TFT color LCD,
Resolution : 1024 x 768
Brightness : high bright 450 cd/m2
Number of color : 16,770,000 true colors
View angle : wide view angles
Contrast ratio : 400 : 1 high contrast ratio
MTBF of backlight tubes : 50,000 hours
Option : Sun-Readable 1700 cd/m2 outdoor LCD
Touch Screen

High quality Resistive touch screen,
Resolution : 4096 x 4096 resolution
Harden treatment : Yes
High / Low temperature treatment : Yes
Cutting resistant
Alcohol resistant

Front Side Bus (FSB)

Support up to very high 1066 / 800 / 533 MHz bus speed.


Support ultra high speed up to 4GB DDR-II RAM.

Video Memory

64MB share memory VGA port

USB 2.0

Support up to 8 USB 2.0.
Speed of USB 2.0 : 480 Mb per second

Serial port

Support 1 x RS232 COM port at the I/O area


Built in 2 stereo speakers.
I/O Port has : Microphone In, Line in, Line out.

Ethernet : LAN Dual fast 100/10 Mbps Ethernet to speed up the networking ability and firewall purpose.


SATA-II high speed 80G / 160G
Support ultra high speed SATA-II HDD.
Standard : SATA-II 80G HDD


support slim type CD-ROM

Parallel Port

LPT port for Printer connection .

Keyboard / Mouse One PS/2 Mouse and one PS/2 Keyboard port
Vibration Resistance Meet IEC-60068 life random vibration test from 5 - 500 Hz at 2G RMS under Windows XP Pro.
Shock Resistance Meet IEC-60068 life Shock Test at 15G for 11ms duration under Windows XP Pro.
Power Supply Built-in 250 watts ATX AC 100-240V power supply.
Storage temperature -40 ~ 80 �XC
Operating Temperature 0 ~ 45 �XC
