| AFOLUX 15"~19" All-In-One Panel PC Series |
 |
|
 |
 |
| AFL-15A-CX |
15" embedded panel PC
VIA C7® (1.5GHz) CPU
with fan or fanless VIA
Eden™ (500MHz) CPU |
 |
Resolution: 1024 x 768 |
|
Brightness (cd/m2): 350 |
|
Touch screen |
|
Integrated audio speakers |
|
512 MB memory preinstalled |
|
Complete I/O support:
- 1 x External SATA
- 1 x RS-232 COM port
- 1 x RS-232/422/485 COM port
- 4 x USB 2.0 ports
- 2 x LAN ports |
|
802.11b/g wireless antenna
inside |
|
Preinstalled Bluetooth module |
|
The best choice for Thin Client,
Windows® CE 5.0 and
Windows® XP embedded |
|
 |
 |
| AFL-17A-CX |
17" embedded panel PC
VIA C7® (1.5GHz) CPU
with fan or fanless VIA
Eden™ (500MHz) CPU |
|
Resolution: 1280 x 1024 |
|
Brightness (cd/m2): 300 |
|
Touch screen |
|
Integrated audio speakers |
|
512 MB memory preinstalled |
|
Complete I/O support:
- 1 x External SATA
- 1 x RS-232 COM port
- 1 x RS-232/422/485 COM port
- 4 x USB 2.0 ports
- 2 x LAN ports |
|
802.11b/g wireless antenna inside |
|
Preinstalled Bluetooth module |
|
The best choice for Thin Client, Windows® CE 5.0 and Windows® XP embedded |
|
|
 |
| AFL-19A-CX |
19" embedded panel PC
VIA C7® (1.5GHz) CPU
with fan or fanless VIA
Eden™ (500MHz) CPU |
|
Resolution: 1280 x 1024 |
|
Brightness (cd/m2): 300 |
|
Touch screen |
|
Integrated audio speakers |
|
512 MB memory preinstalled |
|
Complete I/O support:
- 1 x External SATA
- 1 x RS-232 COM port
- 1 x RS-232/422/485 COM port
- 4 x USB 2.0 ports
- 2 x LAN ports |
|
802.11b/g wireless antenna inside |
|
Preinstalled Bluetooth module |
|
The best choice for Thin Client, Windows® CE 5.0 and Windows® XP embedded |
|
|
|
AFL-15A-CX |
AFL-17A-CX |
AFL-19A-CX |
| LCD Size |
15" |
17" |
19" |
| Max Resolution |
1024 x 768 |
1280 x 1024 |
1280 x 1024 |
| Brightness (cd/m 2 ) |
350 |
300 |
300 |
| Contrast Ratio |
400:1 |
800:1 |
800:1 |
| LCD Color |
262K |
16.7M |
16.7M |
| Pixel Pitch (mm) |
0.297(H) x 0.297(V) |
0.264(H) x 0.264(V) |
0.294(H) x 0.294(V) |
| Viewing Angle (H-V) |
120/100 |
160(H) / 160(V) |
160(H) / 160(V) |
| Backlight MTBF |
50000 |
50000 |
50000 |
| SBC Model |
AFLMB-CX700 |
AFLMB-CX700 |
AFLMB-CX700 |
| CPU |
VIA C7® (1.5GHz) with fan (noise: 35.1dB) |
VIA C7® (1.5GHz) with fan (noise: 39dB) |
VIA C7® (1.5GHz) with fan (noise: 39dB) |
| Chipset |
CX700M |
CX700M |
CX700M |
| RAM |
Supports one 200-pin 1GB (maximum) 400MHz or 533MHz DDR2 SO-DIMM |
| I/O Ports and Switches |
1 x RS-232 COM port
1 x RS-232/422/485 COM port
2 x RJ-45 for GbE
4 x USB 2.0
1 x Power Switch
1 x Reset Button
1 x External SATA |
1 x RS-232 COM port
1 x RS-232/422/485 COM port
2 x RJ-45 for GbE
4 x USB 2.0
1 x Power Switch
1 x Reset Button
1 x External SATA
1 x VGA |
| SSD |
CF Type II |
| Watchdog Timer |
Software programmable supports 1~255 sec. System reset |
| Audio |
AMP 1.5W + 1.5W |
| Expansion |
1 x Mini PCI ( Wireless LAN Module )
1 x Bluetooth Module (USB Interface, Bluetooth V2.0) |
| HDD Drive Bay |
1 x 2.5" IDE/SATA HDD bay
or
Optional GPRS Module |
1 x 2.5" IDE/SATA HDD bay |
1 x 2.5" IDE/SATA HDD bay |
Optional GPRS Module
(support GSM 850,EGSM 900,DCS 1800 & PCS 1900) |
|
Yes |
Yes |
| Construction Material |
ABS + PC Plastic front frame |
| LED Function |
1 x Power ON/OFF LED on front panel |
| Mounting |
Wall, Stand or Arm VESA 100mm x 100mm |
| Front Panel Color |
Silver |
Silver |
Silver |
| Dimension (WxHxD) (mm) |
394 x 309 x 61 |
428 x 350 x 65 |
470 x 383 x 67 |
| Operation Temperature |
0°C ~ 40°C |
| Storage Temperature |
-20°C ~ 60°C |
| Net Weight |
3.2kg |
5kg |
5.6kg |
| IP Level (front panel) |
IP 64 |
| Safety & EMI |
Meet CE, EMC, FCC and CB |
| Touch Screen |
Resistive Type 5-Wire (touch controller IC is on board) |
| Power Adapter |
P/N:63000-FSP0361AD101C-RS
Power: 80W
Input: 90VAC~264VAC @ 50/60Hz
Output:12VDC |
| Power Requirement |
12VDC |
12VDC |
12VDC |
| Power Consumption |
41W |
61W |
64W |
|
AFL-15A-CX-15GZ/WT-R/512MB/**(GPRS01)
|
15"
350cd/m2 panel PC with VIA C7® CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
AFL-15A-CX-05GZ/WT-R/512MB/**(GPRS01)
|
15"
350cd/m2 fanless panel PC with VIA Eden™ CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
AFL-17A-CX-15GZ/WT-R/512MB/**(GPRS01)
|
17" 300cd/m2 panel PC with VIA C7® CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
AFL-17A-CX-05GZ/WT-R/512MB/**(GPRS01)
|
17" 300cd/m2 fanless panel PC with VIA Eden™ CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
AFL-19A-CX-15GZ/WT-R/512MB/**(GPRS01)
|
19" 300cd/m2 panel PC with VIA C7® CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
AFL-19A-CX-05GZ/WT-R/512MB/**(GPRS01)
|
19" 300cd/m2 fanless panel PC with VIA Eden™ CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
| **: Note:For AFL-15A model,if the GPRS module is used, the HDD can't be implemented |
| 1xPower Cable |
1xScrew Kit |
1xHDD Cable |
1xExternal SATA |
| 1xUser Manual-CDROM |
1xTouch Pen |
1xSATA HDD Cable |
1x80W Power Adapter |
|
AFL-15A-CX |
AFL-17A-CX |
AFL-19A-CX |
| Wall mounting kit |
AFLWK-15 |
AFLWK-17 |
AFLWK-19 |
| Stand |
STAND-A19
STAND-B19 |
STAND-A19
STAND-B19 |
STAND-A19
STAND-B19 |
| OS: WIN CE 5.0 |
*AFLCF-15-CX-CE |
*AFLCF-17-CX-CE |
*AFLCF-19-CX-CE |
| OS:WIN XPE |
*AFLCF-15-CX-XPE |
*AFLCF-17-CX-XPE |
*AFLCF-19-CX-XPE |
* Note: Include-CF card, OS image with WINCE or XPE license and theThin Client software package
* CF card capacity with CE 5.0:128MB, with XPE:1GB |
|
|
|
|
|
|
