| AFOLUX 15"~19" All-In-One Panel PC |
 |
|
 |
| |
AFL-15A-915 |
AFL-17A-915 |
AFL-19A-915 |
| LCD Size |
15" |
17" |
19" |
| Max Resolution |
1024 x 768 |
1280 x 1024 |
1280 x 1024 |
| Brightness (cd/m2) |
350 |
300 |
300 |
| Contrast Ratio |
700:1 |
800:1 |
800:1 |
| LCD Color |
262K |
16.7M |
16.7M |
| Pixel Pitch (mm) |
0.297(H) x 0.297(V) |
0.264(H) x 0.264(V) |
0.294(H) x 0.294(V) |
| Viewing Angle (H-V) |
140(H) / 125(V) |
160(H) / 160(V) |
160(H) / 160(V) |
| Backlight MTBF |
50000 |
| SBC Model |
AFLMB-9152-R10 |
| CPU |
Intel® Celeron® M
(1.0GHz) with
512KB L2 Cache |
| Chipset |
Intel® 915GM
Express / 910GMLE |
| Memory |
Supports One 1.0 GB (max.) DDR2 SO-DIMM /
Two 2.0 GB (max.) DDR2 SO-DIMM (Operating Temperature :0°C~35°C) |
| I/O Ports and Switches |
1 x External SATA
1 x RS-232 COM port
1 x RS-232/422/485
COM port
2 x RJ-45 for GbE
4 x USB 2.0
1 x Power Switch
1 x Reset Button
1 x VGA port
1 x Audio |
| SSD |
CF Type II |
| Watchdog Timer |
Software
Programmable
supports 1~255 sec. System reset |
| Audio |
AMP 1.5W + AMP 1.5W |
AMP 1.5W + AMP 1.5W |
AMP 3W + AMP 3W |
| Expansion |
1 x Wireless LAN Module ( Mini PCIe Interface ) |
| HDD Drive Bay |
1 x 2.5" SATA HDD bay |
| Optional GPRS Module(support GSM 850,EGSM 900,DCS 1800 & PCS1900) |
N/A |
| Construction Material |
ABS + PC Plastic front frame |
| LED Functions |
1 x Power ON/OFF LED on front panel |
| Mounting |
Panel, Wall, Rack, Stand and Arm (VESA 100mm x 100mm) |
| Front Panel Color |
Silver |
| Dimension (WxHxD) (mm) |
394 x 309 x 61 |
428 x 350 x 65 |
470x 383 x 67 |
Operation
Temperature (°C) |
0°C~40°C with HDD |
| 0°C~45°C with CF card or SATA interface 2.5" SSD HDD |
| Storate Temperature (°C) |
-20°C~60°C |
| Net Weight |
3.7 Kg |
5.4 Kg |
5.8 Kg |
| IP Level (front panel) |
IP 64 |
| EMC |
CE,FCC,CCC,CB |
| Safety |
UL,CCC |
| Touch Screen |
Resistive Type 5-Wire (touch controller IC is on board) |
| Power Adapter |
Power: 60W
Input: 90VAC~264VAC @50/60Hz
Output:12VDC |
Power: 84W
Input: 90VAC~264VAC @50/60Hz
Output:12VDC |
Power: 84W
Input: 90VAC~264VAC @50/60Hz
Output:12VDC |
| Power Requirement |
12VDC |
| Power Consumption |
38W |
52W |
54W |
|
| Optional Internal GPRS Spec (P/N: GPRS01) |
EDGE/GPRS/GSM
Air interface |
Quad-band operation GSM850, EGSM 900, DCS 1800, PCS 1900 |
| GSM Power Class 4 (2W) for 850/900 bands, GSM Power Class 1 (1W) for 1800/1900 bands |
| EDGE class E2 (+27dBm in 850/900 bands, +26dBm in 1800/1900 bands) |
| GSM/GPRS Rel '97; PCS1900 Rel '98; EGPRS Rel '99 compliant |
| EGPRS/GPRS (PS) feature set |
GPRS Class 10, coding schemes 1-4 |
| EDGE Class 10, Multi-slot classes 1-9 |
| GPRS/EGPRS class B type 1 MT |
| Link Adaptation |
| Incremental redundancy (IR) |
| Operating System Supported |
Windows 2000/XP Home/XP Pro |
| USB Interface |
USB2.0 +5V DC |
| SIM Card Interface |
3.0V interface |
| Temperature |
-30°C to +65°C |
| Humidity |
up to 95% non-condensing |
| Dimensions |
109.3 x 42.7 x 17.7mm |
|
| Standard |
Bluetooth V2.0 |
| Frequency Band |
2.402GHz ~ 2.480GHz unlicensed ISM band |
| Modulation Method |
GFSK for 1Mbps; Π/4-DQPSK for 2Mbps; 8-DPSK for 3Mbps |
| Spread Spectrum |
FHSS (Frequency Hopping Spread Spectrum) |
| RF Output Power |
Class 2 (under 4 dBm) |
| Antenna terminal |
50 Ohms |
| DC power |
DC 3.3 V or DC 5V |
| I/O interface |
USB v2.0 compliant interface |
| Two GPIO interface |
LED link indicator interface |
| Dimension |
35 x 11 mm |
| Operating system supported |
Windows XP, 2000, 98SE, Me |
| LCD Size |
15" |
17" |
19" |
| Panel mounting kit |
AFLPK-15 |
AFLPK-17 |
AFLPK-19 |
| Wall mounting kit |
AFLWK-19 |
| Rack mounting kit |
AFLRK-15 |
AFLRK-17 |
N/A |
| LCD Monitor Stand |
STAND-A19 / STAND-B19 |
| OS: WIN CE 5.0 |
AFLCF-15-915-CE050 |
AFLCF-17-915-CE050 |
AFLCF-19-915-
CE050 |
| OS: WIN CE 6.0 |
AFLCF-15-915-CE060 |
AFLCF-17-915-CE060 |
AFLCF-19-915-
CE060 |
| OS:WIN XPE |
AFLCF-15-915-
XPE |
AFLCF-17-915-
XPE |
AFLCF-19-915-
XPE |
* OS image with WINCE or WPE license and IEI Thin Client software package included in the CF card
* CCF card capacity with CE 5.0/CE 6.0:128MB, with XPE:1GB |
AFL-15A-915-10G/WT-R/512MB
|
15" XGA panel PC w/ Celeron M 1.0GHz 512K cache CPU, 512MB DDR2
RAM, 802.11 b/g wireless module, touch screen, Bluetooth, RoHS |
AFL-17A-915-10G/WT-R/512MB
|
17" SXGA panel PC w/ Celeron M 1.0GHz 512K cache CPU,512MB DDR2
RAM, 802.11 b/g wireless module, touch screen, Bluetooth, RoHS |
AFL-19A-915-10G/WT-R/512MB
|
19" SXGA panel PC w/ Celeron M 1.0GHz 512K cache CPU, 512MB DDR2
RAM, 802.11 b/g wireless module, touch screen, Bluetooth, RoHS |
AFL-19A-915-10G/WT-R/512MB/GPRS01
|
19" SXGA panel PC w/ Celeron M 1.0GHz 512K cache CPU, 512MB DDR2 RAM, 802.11b/g wireless module, Bluetooth module and touch screen, RoHS |
| ** (GPRS01) for optional GPRS module. GPRS module for AFL-19A model only |
| 1xPower Cable |
1x User Manual-CDROM |
| 1x Screw Kit |
1x Touch Pen |
| 1x SATA HDD Cable |
11x External SATA Cable |
1x 60W Power Adapter
(For AFL-15A-915) |
1x 84W Power Adapter
(For AFL-17A-915 and AFL-19A-915) |
|
|
 |
|
|
|
